PreSonus NSB 16.8 AVB Networked Stage Box
(Incl. Taxes)
Designed to work seamlessly with PreSonus® StudioLive® Series III mixers, the PreSonus NSB 16.8 stage box offers 16 locking combo mic/line inputs with remote-controlled XMAX preamps that include gain compensation for shared input scenarios. You also get 16 direct inputs via AVB. All inputs can be controlled from a StudioLive Series III console and from free PreSonus UC Surface software. All eight outputs employ locking XLR jacks. A built-in 2-port AVB switch lets you daisy-chain multiple units. A rugged steel chassis with sturdy handles and a stage box form factor allow the NSB 16.8 to sit well on the stage and survive the rigours of the road. The unit can be rack-mounted with an optional rack-ear kit.
Features:
- Rugged stage box enclosure with handles
- 16 locking mic/line inputs and 8 locking XLR outputs
- 16 remote-controllable XMAX preamps
- Gain compensation for shared inputs
- 2 AVB ports with locking XLR Ethernet jacks
- 32x8 AVB (16 direct input channels + 16 gain-compensated input channels)
- Easy setup and control from StudioLive® Series III consoles and from free PreSonus® UC Surface software
- Mic Input Type: XLR Balanced Female, 20-20 kHz, ±0.5 dBu Frequency Response, 48 VDC Phantom Power (Switchable per channel)
- Line Input Type: 1⁄4” TRS Balanced Female, 20-20 kHz, ±0.5 dBu Frequency Response
- XLR Outputs: XLR Balanced Male, 100Ω Output Impedance
- Power: IEC, 90 to 230 VAC (±10%)
- Includes: PreSonus NSB 16.8 AVB Networked Stage Box, IEC Power Cord
- Dimensions: 16.7” (W) x 4.5” (D) x 7" (H) / 424mm (W) x 114mm (D) x 178mm (H)
- Weight: 2.8 kg / 6.2 lbs.
PRODUCT HIGHLIGHTS
- StudioLive Synergy
- Remote XMAX
- Road Proven
- AVB Networking
